GOCONTROLE

type d	L1 Thread diameter	L2 Thread diameter	L3 Thread diameter	L4 Thread diameter	L5 Thread diameter
m4	0,5 - 1,5	1,5 - 2,5	2,5 - 3,5	3	4,5 - 5,5
m5	0,5 - 2,0	2,0 - 3,0	3,0 - 4,0	4	0
m6	0,5 - 2,5	2,5 - 4,0	4,0 - 5,5	5	0
m8	1,0 - 3,0	3,0 - 5,0	4,5 - 6,5	6	0
m10	1,0 - 3,5	3,5 - 6,0	6,0 - 8,5	0	0

type d	L1 Thread diameter	L2 Thread diameter	L3 Thread diameter	L4 Thread diameter
m4	0,5 – 4,0	2,5 – 5,5	4,0 - 7,0	0
m5	0,5 – 5,0	3,0 – 7,0	0	0
m6	0,5 – 4,5	5,0 – 6,0	4,0 - 9,0	0
m8	0,5 – 6,0	0,5 – 8,0	4,5 - 11,0	6
m10	0,8 – 7,0	1,5 – 10,0	5,5 - 14,0	0

type d	L1 Thread diameter	L2 Thread diameter	L3 Thread diameter
m5	0,7 - 2,5	2,5 - 4,0	0
m6	1,0 - 3,0	3,0 - 5,0	0
m8	1,5 - 4,0	4,0 - 6,0	6,0 - 8,0
m10	2,0 - 5,0	4,5 - 7,0	6,5 - 9,0

type d	L1 Thread diameter	L2 Thread diameter	L3 Thread diameter	L4 Thread diameter	L5 Thread diameter	L6 Thread diameter
m4	0,5 - 0,8	0,5 – 1,8	1,5 - 2,0	1	0	0
m5	0,7 - 1,0	0,7 - 2,0	2,0 - 2,5	2	0	0
m6	0,7 - 1,0	0,7 - 2,0	2,0 - 2,5	2	0	0
m8	0,7 - 1,5	0,7 - 2,5	2,0 - 3,0	2	3,5 - 4,5	3,5 - 5,5

type d	L1 Thread diameter	L2 Thread diameter	L3 Thread diameter
m4	0,3 - 0,8	0,8 - 1,5	0
m5	0,5 - 1,0	1,0 - 2,0	0
m6	0,5 - 1,0	1,0 - 2,0	0
m8	0,5 - 1,2	1,0 - 2,5	2,0 - 4,0

DEGOMETAL is able to consider any request for the manufacture of fastening products tailor-made.
The mechanical characteristics of our rivets can be adjusted according to your needs.
DEGOMETAL delivers perfectly adapted, high-quality solutions either directly off-plan or through an analysis of our customer's technical specifications.
